AURO OtoSys IM600 Questions and Answers

Here are questions and answers of AURO OtoSys IM600 key programming tool, which helps you out.


Look here:

Q: Is this IM600 any good? Pros and cons?

A: For diagnosis and programming of some modules this is perfect

Works very well in that module programming. to schedule keys still missing

Q: Is it different between Auro OtoSys IM100 and IM600 in immobilizer functions?

A: Main difference lies in Mercedes, VW, Audi software

Software is Same but differ hardware. IM100 use UP200. IM600 use UP400.

Up200 doesn’t allow for eeprom and use of breakout leads through the custom pinouts.

Q: Does it have bi directional controls?

A: Not the im100

The im600 has full bi-directional controls active test special functions

Q: Hello guys, where did you get you IM600?

A: I bought it on . That’s good.

Q: A question to the lads on this page before my company buys this machine Im600 what cars have you successfully done a key for?

A: 2007 Nissan titan, 2007 Chrysler Sebring, 2008 Volkswagen, 2010 Nissan, 2000-2012 ford and a few others

Q: Can someone post the full details of AURO OTOSYS IM600 ?

check official website

Q: 2010 Chrysler Town and Country…major fail which is surprising since so many other China tools work

A: Pin code reading is not available yet 🙁 I was able to do a 2010 Jeep G Cherokee, when I used the 820 to pull the pin

Q: I just purchased Im600 but I dt know may be I still need Pin Code Caculator, such as ICC or CWP?

A: Looks like it doesn’t pull pin codes.

Q: Does anyone know how to add key BMW E90 with CAS module by IM600?

A: Wait for the update. Tried a bmw and Benz this weekend. Couldn’t do much. I think the next update is June

Q: Does the IM 600 provide Benz IMMO?
I don’t see it in list of immo program.

A: It’s a future update.

Q: Does the IM600 support add key Toyota G and H chip & all keys lost ?

A: Yes.

Q: When can we see Mercedes bmw and more vw audi software immo coming out? the suspense is killing me

A: Engineers are working hard on the software development now, plan to finish some software on August or September. We will keep pushing them. Thank you very much for your feedback!

Q: Does Auro Sys IM600 do mercedes al keys lost????

A: Nope. The future update will add Benz. but now vvdi mb should work good

Q: Can the im600 pull a pin code 02 jeep liberty?

A: No

Q: Can I have the same function of BMW in ACDP if I have an Im600?

A: IM600 for BMW FEM/ BDC only, not for CAS and EWS

So, Yanhua ACDP will be better

Q: I just got an IM600. Can someone confirm. it will not program Ford keys?

A: Currently it will not program them under immo. There is some stuff under diagnostics. The update for them is in a month or so

Edit to update: Auro Im600 Ford Immo added!

Q: I’m yet to be impressed with my Auro IM100, it has no Ford immo, and can’t do 2013 corolla all key lost.

A: Ford IMMO has been updated on 05.2018; pls kindly register your IM100 and go to Update page to download the software, thank you!

More FAQs of Auro IM600 will be updated here…

Free download NEW K-Suite 2.47 for Kess 5.017

NEW K-Suite 2.47 for Kess 5.017 adds exactly 7400 vehicles.

we provide  the sources of K-Suite 2.47 download link.


Source 1:

Ksuite_2.47 for Kess v2 5.017 clone!Sx8i3JQK!XC2WUVHJCSf3bKg4niJhyaL3444uz8GcSvCXmZi4jeI


No need HWID and KG.
Unpack DLL from archive in folder Ksuite/DLL.


■Credits to svvag2000of forum.

PS: With clean new install 2.47 ,work fine on all 32 bit, win7 64bit and x86.
newer DLL files also installed.

Setup instruction: Unpack ksuite and unpack dll files and copy dll files in dll folder in new ksuite 2.47 folder and run ksuite.exe from there. Don’t copy new ksuite in old install folder.

Source 2:

1.Download Software:!r8wDSbjL!B8saSeQWJE4edxgZ7KJJHPqCmxigtZQ2JpMPw_Su5MY


2.Run Software and Click Ctrl + C to copy Machine ID
3.Past your Machine id to get One/Working license to run your software
License Locked to one PC Machine

Source: volavka (poster of

Already tested on Polo 2011 tdi with PCR 2.1 unlock by obd. unlocking of PCR2.1 eeprom work all by obd like cmd..activate mod.yob done.

PS: Ktag 7.020 only works with 2.25 highest. 2.47 is for Kess 5.017

Here an image of online version of Kess 5.017 which won’t be locked after connecting online.


Reliable source:

K-Suite 2.47 compare with 2.23:

Caterpillar A5E2 P549
VOLVO 1.6/2.0 Continental SID807 P489
Husquarna KEIHIN P554
ALL SIMOS18 18.1 18.2 NEW GENERATION 4,5mb

Installing a higher version of Ksuite does not bring new protocols but adds ECUs to existing protocols and a lot of bug fixes and checksums fixes, Simos18 4.5MB…
This is not useless and the grayed out protocols are not really a problem.

And Ksuite 2.47 is even better with Kess firmware v2 5.028. Work with simos18 very good. If you don’t have a good Kess fw 5.028, firmware 5.017 is the best online option for you.

K-Suite 2.47 adds 7400 Vehicles shown as below.
